The ReynoArch WPC Trio+ Louvers is an engineered cladding and ceiling solution developed for high-performance architectural applications. Designed for façade articulation, and Exterior ceiling integration, the system combines structural stability, environmental resistance, and aesthetic flexibility.
Manufactured using advanced Wood Polymer Composite (WPC) technology, the panels are engineered to deliver dimensional stability, low moisture absorption, UV resistance, and long-term structural performance in exterior conditions.
The system is suitable for:
- Exterior façades
- Soffits and overhangs
- Balcony ceilings
- Entrance canopies
- Interior feature ceilings and wall cladding
- Commercial and residential developments
Material Composition
- Core Material: Wood Polymer Composite (WPC)
- Profile Design: 2.2 mm thick solid panel for weight optimization and structural rigidity
- Surface Finish: UV-stabilized exterior-grade finish
- Installation System: Interlocking profile with compatible accessories
Performance Characteristics
Structural & Mechanical
- High impact resistance
- Optimized load distribution via solid flute design
- Lightweight construction reducing dead load
- Dimensional stability under temperature variation
Environmental Resistance
- UV-stabilized surface
- Waterproof and moisture-resistant
- Termite and fungus resistant
- Corrosion-resistant (non-metallic substrate)
Fire & Safety
- B-1 Fire-retardant grade
Thermal & Acoustic
- Thermal insulation support for Exterior Cladding and Ceiling Cladding
Sustainability
- Recyclable material composition
- Reduced carbon footprint compared to traditional wood
- Low maintenance lifecycle
For 3 Flute Trio+ Series
SPECIFICATION: T Trim Profile
Size – 2900 mm
Pc. per Box: 10 Pcs.
SPECIFICATION: J Trim Profile
Size – 2900 mm
Pc. per Box: 10 Pcs.
SPECIFICATION: Inner Corner Profile
Size – 2900 mm
Pc. per Box: 10 Pcs.
SPECIFICATION: Outer Corner Profile
Size – 2900 mm
Pc. per Box: 10 Pcs.
For 4 Flute Trio+ Series, Curvy Trio+ Series
SPECIFICATION: J Trim Profile
Size – 2900 mm
Pc. per Box: 10 Pcs.
FAQ's
The Soffit Panel of building ceilings and walls create a glossy look and provide many functional benefits, including higher-level airflow, moisture and chemical immunity, and lower overall energy costs.
ReynoArch has made the Soffit Panel highly durable, weather-resistant, light, and maintenance-friendly. While this soffit panel is also energy efficient and sound abatement, its varying colors and textures serve modern architectural design for interiors and exteriors.
The purpose of Soffit Panel is to hide structural elements, creating an elegant look. The Soffit Panel is the backbone of modern outdoor and indoor design, providing both practicality and beauty for housing and corporate spaces. Therefore, Soffit Panel are used most commonly to protect balcony ceilings, and more.
By providing a route for airflow through the roof’s edge, Soffit Panel help reduce moisture buildup and confined heat within the airspace below the roof. In addition, Soffit Panel contain auditory insulation that will assist in maintaining warmer spaces and preventing damage caused by exposure.
The Soffit Panel, from an architect’s or builder’s standpoint, has both utility and style. An architect and builder are able to improve the overall aesthetics of a building and provide structural support at the same time because of the strength, durability, and energy-efficient qualities of the Soffit Panel, combined with the contemporary appearance that the Soffit Panel provides to modern-day structures.
